Brand Name:OMF Condition:New Supply Voltage:4-38V Dissipation Power:5A Operating Temperature:-40-+85 Model Number:XL4015 is_customized:Yes Package:SOP Type:Charging Board Application:Charging Board

Product Description Please read before buying: Because ordinary parcels do not have tracking information, so encountered the peak season of logistics, ordinary parcels will be extended to arrive, so if you mind the speed of logistics, please pay the registration fee, with faster logistics speed. When encountering slight product damage, bent pins, and scratches on the case, we will not accept refunds of disputes if they do not affect use . If you mind this situation, please do not purchase my product. When you buy my product, it is the default acceptance of this article! ! ! So we will not accept your dispute. D-2 Large current 5A constant current LED driver lithium-ion battery power supply module 5A constant voltage constant current module When you use this product, the module inputs and outputs to the ground and do not co-together, this will cause the board power current sense resistor is bypassed, so that the module can not adjust the output current size, the case then load easy to burn power chip module. This module is easy to use, powerful! ! ! A module has three major features to meet most of your occasions! ! ! Module Description: 1. high power, high efficiency, 5A, low ripple; 2. triple: (1) Use as a normal blood pressure modules with overcurrent protection capability; (2) as the various voltage lithium batteries, batteries, nickel-cadmium nickel-metal hydride batteries (battery) charger for solar panels, wind turbines and other occasions; (3) is used as a high-power LED constant current drive module; 3. With constant pressure and constant current modes, there are light indicates which mode is currently in module; 4. When used as a lithium battery charger, you can set the float voltage and the charge current size, there is light indicates is being charged or has been filled; 5. Has the current limit protection, output short circuit even if it will not burn module. 6. This module uses machine placement, reflow soldering, and each module shipments have been two hours before the aging tests to ensure high reliability. D-3 Input: IN + input positive, IN- input negative Output way: OUT + output positive, OUT- output negative Input voltage: 4-38V Output voltage: 1.25-36V continuously adjustable Output current: adjustable, maximum 5A Output Power: 75W maximum Working temperature: -40 to + 85 degrees Operating frequency: 180KHz Conversion efficiency: up to 96% Short circuit protection: Yes (limit current 8A) Overtemperature protection: (automatically shut off the output after overtemperature) Input reverse polarity protection: None, (if necessary, please enter the string into the high current diode) Installation: four 3mm screws Module dimensions: length 51mm width 26mm height 15mm D-3 1. Use as a normal blood pressure modules with overcurrent protection capability Instructions: (1) constant pressure regulator potentiometer, the output voltage reaches the voltage value you want (2) 10A current with a multimeter measuring the output short circuit current file (directly to the two leads to the output can), while adjusting the constant current potentiometer allows the output current reaches a predetermined value of overcurrent protection. (Such as the current value of the multimeter displays 4A, then you can use the module to the maximum current 4A, 4A current to constant voltage constant current when the red light is on, otherwise the light off) Note: When used in this state, since the output of 0.05 ohm current sense resistor, there will be 0 ~ 0.3V voltage drop after connected to the load, this is normal! This drop is not being pulled down your load, but down-sampling resistor. 2. Use as a battery charger Module without constant function can not be used to charge the battery, since the end of the battery and charger power consumption big difference between charging current is too large, resulting in damage to the battery, so when you want to start the battery using a constant current charging, when charging to a certain extent automatically switches back to constant voltage charging. Instructions: (1) Make sure you need to recharge battery float voltage and charging current; (if lithium argument is 3.7V / 2200mAh, then float voltage is 4.2V, the maximum charging current 1C, namely 2200mA) (2) under no-load conditions, the multimeter to measure the output voltage of the constant voltage potentiometer to adjust the output voltage reaches the float voltage; (if rechargeable lithium battery to 3.7V, the output voltage can be adjusted to 4.2V) (3) 10A current with a multimeter measuring the output short circuit current file (directly to the two leads to the output can), while adjusting the constant current potentiometer allows the output current reaches a predetermined charge current value; (4) Charging turn lamp current default factory setting is 0.1 times the char
